Output Max Configurable Power (Watts) 360 Watts / 700VA Output Frequency (sync to mains) 50/60 Hz +/- 1 Hz Sync to mains Topology Line interactive Waveform type Stepped approximation to a sinewave Transfer Time 6 ms typical : 10 ms maximum Input Input frequency 50/60 Hz +/- 5 Hz Auto-sensing Input voltage range for main operations 170 – 280 (230 V) ACV Number of Power Cords Input Power Factor at Full Load 0.51 Batteries & Runtime Battery type Lead-acid battery Typical recharge time 8hour(s) Nominal Battery Voltage 12 V Expected Battery Life (years) 2 – 3 Battery Volt-Amp-Hour Capacity Runtime View Runtime Graph Efficiency View Efficiency Graph Communications & Management Control panel LED Status display with on line : on battery Audible Alarm Alarm when on battery : distinctive low battery alarm Surge Protection and Filtering Surge energy rating 273Joules Physical Maximum Height 138MM, 13.8CM Maximum Width 98MM, 9.8CM Maximum Depth 310MM, 31.0CM Net Weight 4.2KG Shipping weight 4.5KG Shipping Height 222MM, 22.2CM Shipping Width 142MM, 14.2CM Shipping Depth 346MM, 34.6CM Color Black SCC Codes 10731304417610 Environmental Operating Temperature 0 – 40 °C Operating Relative Humidity 0 – 95 (Non-condensing) % Operating Elevation 0 – 3000meters Storage Temperature -15 – 40 °C Storage Relative Humidity 0 – 95 (Non-condensing) % Storage Elevation 0 – 3000meters Audible noise at 1 meter from surface of unit 40.0dBA Protection Class IP20 Your Name Your Review Note: HTML is not translated! Rating Bad Good Continue
