Output Max Configurable Power (Watts) 6.0kWatts / 6.0kVA Output Voltage Note Configurable for 220 : 230 or 240 nominal output voltage Efficiency at Full Load 94.0 % Output Voltage Distortion 1 % Output Frequency (sync to mains) 50/60 Hz +/- 3 Hz Sync to mains Other Output Voltages 220 V, 240 V Load Crest Factor 3 : 1 Topology Double conversion online Waveform type Sine wave Bypass Internal bypass (automatic and manual) Input Input frequency 40 - 70 Hz Auto sensing Input voltage range for main operations % load, Full loadV Efficiency at Full Load 94.0 % Other Input Voltages 220 V, 240 V Batteries & Runtime Battery type Lead-acid battery Typical recharge time 4hour(s) Nominal Battery Voltage 192 V Expected Battery Life (years) 3 - 5 Battery Charge Power (Watts) 235 Watts Runtime View Runtime Graph Efficiency View Efficiency Graph Communications & Management Interface Port(s) DB-9 RS-232, Intelligent Smart Slot, USB Control panel Multifunction LCD status and control console Emergency Power Off (EPO) Yes Available SmartSlot™ Interface Quantity Surge Protection and Filtering Surge energy rating 600Joules Physical Maximum Height 685MM, 68.5CM Maximum Width 190MM, 19.0CM Maximum Depth 374MM, 37.4CM Net Weight 54.0KG Shipping weight 66.0KG Shipping Height 910MM, 91.0CM Shipping Width 290MM, 29.0CM Shipping Depth 495MM, 49.5CM Color Black Environmental Operating Temperature 0 - 40 °C Operating Relative Humidity 0 - 95 (Non-condensing) % Operating Elevation meters Storage Temperature -15 - 60 °C Storage Relative Humidity 0 - 95 (Non-condensing) % Storage Elevation meters Audible noise at 1 meter from surface of unit 55.0dBA Online thermal dissipation 1172.0BTU/hr Protection Class IP20 Conformance Approvals CE, EAC, TISI, UKCA Standard warranty 2 years repair or replace Sustainable Offer Status RoHS Compliant Please to review
