| Exterior Color |
Black, White |
|
| Materials - Outlook |
Steel, Mesh, Plastic |
|
| Materials - Side Panel |
Tempered Glass, Steel |
|
| Dimensions (L x W x H) |
516 x 224 x 510mm (incl. Protrusions) |
|
| Motherboard Support |
ITX, Micro ATX, ATX, SSI CEB, E-ATX*, (*up to 12" x 14.1", may impact cable management and case features, remove cable cover and GPU fan bracket features) |
|
|
|
| 2.5" / 3.5" Drive Bays (Combo) |
2 |
|
|
| I/O Panel |
2x USB 3.2 Gen 1 (formerly USB 3.0), 1x USB 3.2 Gen 2 Type-C, 1x single Audio Jack, 1x Reset/ARGB button |
|
|
| Pre-installed Fans - Front |
2x 200mm ARGB Fan |
|
| Pre-installed Fans - Rear |
1x 120mm SickleFlow PWM ARGB |
|
| Pre-installed Fans - Top on HDD cage |
1x 120mm SickleFlow PWM (GPU Fan) |
|
| Fan Support - Top |
3x 120mm, 2x 140mm, 2x 200mm |
|
| Fan Support - Front |
3x 120mm, 2x 140mm, 2x 200mm, *200mm Mounting Hole Spacing 154 x 154 w/ up to 30mm thickness |
|
| Fan Support - Rear |
1x 120mm |
|
| Fan Support - Top on HDD cage |
1x 120mm |
|
| Radiator Support - Top |
120mm, 140mm, 240mm, 280mm, 360mm |
|
| Radiator Support - Front |
120mm, 140mm, 200mm, 240mm, 280mm, 360mm |
|
| Radiator Support - Rear |
120mm |
|
| Clearance - CPU Cooler |
167mm/6.5" |
|
| Clearance - PSU |
180mm/7.1" |
|
| Clearance - GFX |
410mm/16.1" |
|
| Cable Routing - Behind Motherboard Tray |
30mm |
|
|
| Power Supply Support |
Bottom Mount, ATX |
|
|
|
|
