| Model Number |
MB520-KGNN-S01, MB520-WGNN-S01 |
|
| Exterior Color |
Black, White |
|
| Materials - Exterior |
Steel, ABS Plastic, Tempered Glass |
|
| Materials - Left Side Panel |
Tempered Glass |
|
| Dimensions (L x W x H) |
502 x 210 x 498mm (Incl. Protrusions), 443 x 210 x 498mm (Body Size) |
|
|
| Motherboard Support |
Mini ITX, Micro ATX, ATX, SSI CEB, E-ATX*, (*up to 12" x 10.7" motherboards, may impact cable management feature) |
|
|
|
|
| I/O Panel |
1x USB 3.2 Gen 1 Type-A, 1x USB 3.2 Gen 2 Type-C, 1x 3.5mm Headset Jack (Audio+Mic), 1x Reset/ARGB button |
|
| Included Accessories |
ARGB Fans Hub |
|
| Pre-installed Fans - Front |
3x CF120 ARGB |
|
| Pre-installed Fans - Rear |
1x MasterFan Lite 120 |
|
| Fan Support - Top |
3x 120mm, 2x 140mm |
|
| Fan Support - Front |
3x 120mm, 2x 140mm |
|
| Fan Support - Rear |
1x 120mm |
|
| Radiator Support - Top |
120mm, 140mm, 240mm, 280mm, 360mm, (recommended maximum thickness -55mm) |
|
| Radiator Support - Front |
120mm, 140mm, 240mm, 280mm, 360mm |
|
| Radiator Support - Rear |
120mm |
|
| Clearance - CPU Cooler |
165mm / 6.49" |
|
| Clearance - PSU |
200mm, (Recommended up to 170mm) |
|
| Clearance - GFX |
410mm/16.1" |
|
| Dust Filters |
Bottom, Front, Top |
|
|
|
|
|
