PSU Specifications
| AC INPUT: 100-240 VAC 15-5A 50-60Hz | |||||
| DC Output Max |
+3.3V | +5V | +12V | -12V | +5VSB |
| 20A | 20A | 70A | 0.5A | 2.5A | |
| 1050W | |||||
Detailed Specifications
| Dimensions: | 160mm x 85mm x 150mm (W x H x D) |
| Input Voltage: | 100-240 VAC |
| Input Current: | 15-5A |
| Input Frequency Range: | 50-60Hz |
| PFC: | Active PFC (>.99) |
| Power Good Signal: | 100-150 ms |
| Hold Up Time: | >9ms |
| Efficiency: | ＞85%（89%max) |
| MTBF: | > 100,000 Hours |
| Protection: | OPP / OVP/ UVP / OCP/ SCP / OTP / SIP / OLP / NLO |
| Power: | 1050W |
| Operation Temperature: | 0-40C |
| Safety: | CE / FCC / CB |
| Cooling: | 140mm Ultra Silent Fan |
| Noise: | <25dBa |
| 80 Plus Certified: | Yes - 80 Plus Silver |
