The LDNIO SC3 is a 10-in-1 GaN desktop charging station and power strip designed to centralize AC power and USB charging on a desk or workstation. It combines three AC outlets, three USB-C outputs, three USB-A outputs and one Lightning output in a single desktop unit. With up to 100W total charging power and 2500W maximum AC output, the SC3 supports a wide range of fast-charging protocols including PD, QC, PPS, SCP, FCP and AFC. A master switch and 75N child safety shutters are also integrated into the design. Key Features 10-in-1 Desktop Design: Combines 3 AC outlets, 3 USB-C outputs, 3 USB-A outputs and 1 Lightning output. 100W GaN Charging: Provides up to 100W total charging power using GaN technology. 2500W AC Output: Three wide-spaced AC outlets support a maximum rated power of 2500W. Broad Fast-Charging Support: Compatible with PD3.0, PD2.0, QC3.0, QC2.0, PPS, SCP, FCP, AFC and Samsung DCP protocols. Multiple Output Levels: USB-C outputs support up to 65W or 35W depending on the port, while USB-A1 supports up to 27W. Safety-Focused Controls: Includes a master switch and 75N child safety shutters. Technical Specifications Component Specification LDNIO Model SC3 Produ Type GaN Desktop Charging Station / Power Strip Total Connections 10-in-1 AC Outlets USB-C Outputs USB-A Outputs Lightning Output Rated Power 100–250 V~ 50/60 Hz, 10 A, 2500 W Max Total Charging Power 100 W Max Lightning / USB-C1 PD Output 5 V⎓3 A, 9 V⎓3 A, 12 V⎓3 A, 15 V⎓3 A, 20 V⎓3.25 A Lightning / USB-C1 PPS 3.3–16 V⎓3 A, 3.3–21 V⎓3 A, 65 W Max USB-C2 / USB-C3 PD Output 5 V⎓3 A, 9 V⎓3 A, 12 V⎓2.92 A, 15 V⎓2.33 A, 20 V⎓1.75 A USB-C2 / USB-C3 PPS 3.3–11 V⎓3 A, 35 W Max USB-A1 Output 5 V⎓3 A, 9 V⎓3 A, 12 V⎓2.25 A, 20 V⎓1.35 A, 27 W Max USB-A2 / USB-A3 Output 5 V⎓2.4 A, 12 W Max Charging Protocols PD3.0, PD2.0, QC3.0, QC2.0, PPS, SCP, FCP, AFC, Samsung DCP Safety Features Master switch, 75N child safety shutter Plug Options EU, UK, US Compatibility & Important Information The SC3 supports a maximum total USB charging output of 100 W. Individual USB output capability varies by port; USB-C1 supports up to 65 W, USB-C2 and USB-C3 support up to 35 W each, and USB-A1 supports up to 27 W. The three AC outlets are rated for up to 2500 W total at 100–250 V~, 50/60 Hz and 10 A. LDNIO lists EU, UK and US plug versions for the SC3. Fast-charging performance depends on the connected device, charging protocol and port used. Please to review Q: How many connections does the LDNIO SC3 provide? A: The SC3 is a 10-in-1 charging station with 3 AC outlets, 3 USB-C outputs, 3 USB-A outputs and 1 Lightning output. Q: What is the maximum USB charging power? A: The SC3 supports up to 100 W total charging power. Q: What is the maximum output of USB-C1? A: USB-C1 supports PD output up to 65 W, including PPS ranges of 3.3–16 V⎓3 A and 3.3–21 V⎓3 A. Q: How powerful are the AC outlets? A: The AC section is rated at 100–250 V~, 50/60 Hz, 10 A and up to 2500 W maximum total power. Q: Which fast-charging protocols does the SC3 support? A: LDNIO lists support for PD3.0, PD2.0, QC3.0, QC2.0, PPS, SCP, FCP, AFC and Samsung DCP. Q: Does the LDNIO SC3 have child safety shutters? A: Yes. LDNIO specifies 75N child safety shutters together with a master switch. Q: Which plug versions are available? A: LDNIO lists EU, UK and US plug versions for the SC3.
