- Power Supply Mode:Standard POE power supply/48V non-standard POE power supply
- Power Consumption:<3W
- Network Port Gigabit:PoE IN:1000Mbps/PoE OUT:1000Mbps
- Transmission Distance:100m(Single-stage connection);400m(Multi-level connection) The relationship between transmission distance and power is shown in Figure 1
- Transmission Medium:Cat5e/6
- PoE Protocol:Support IEEE802.3af. IEEE802.3at protocol
- PoE Power Receiving Method:Compatible with end-span and mid-span methods
- Network Standard:IEEE802.3u100Base-TX
- Network Delay:Non-store-and-forward, 0 delay
- Indicator LED:PoE IN port and PoE OUT port: RJ45 yellow indicator light PoE status:green light indicates network working status
- Electrostatic Protection:1a Contact discharge level 3; 1b Air discharge level 3
- Communication Port Lightning Protection:3 level
- Storage Environment:-40°C-85°C
- Working Temperature:-10°C-55°C
- Humidity(non-condensing):0-95%
- Fuselage Properties
- Size(Length Width*Height):145mmx99×32mm
- Material:ABS+PC flame retardant
- Color:White
- Weight(Gross weight):163.3g
