The Synology DiskStation DS725neo+ is a compa 2-bay network attached storage (NAS) server designed for centralized file storage, data backup, private cloud access and collaboration. Powered by an AMD Ryzen R1600 dual-core processor and equipped with 4 GB DDR4 non-ECC memory, it provides a versatile storage solution for homes, small businesses and remote offices. With built-in 2.5GbE networking, an additional 1GbE LAN port, two M.2 NVMe SSD slots and support for expansion to seven drive bays using a Synology DX525 expansion unit, the DS725neo+ combines compa dimensions with flexible storage growth. Synology DiskStation Manager (DSM) provides integrated tools for managing files, backups and shared storage. Key Features Expandable 2-Bay Storage: Supports two 3.5-inch SATA HDDs or 2.5-inch SATA SSDs, with expansion to seven bays using one compatible DX525 unit. AMD Ryzen Processing: AMD Ryzen R1600 dual-core processor with four threads and frequencies of 2.6 GHz base and 3.1 GHz turbo. Expandable Memory: Includes 4 GB DDR4 non-ECC SODIMM memory and supports expansion up to 32 GB. Flexible Network Connectivity: Integrated 2.5GbE and 1GbE RJ-45 LAN ports for wired network connections. NVMe SSD Caching: Two M.2 2280 NVMe SSD slots support compatible SSD cache configurations. Synology DSM: Centralized file sharing, backup management, private cloud synchronization and RAID storage management. Technical Specifications Component Specification Synology Model DS725neo+ Produ Type 2-Bay Desktop NAS Processor AMD Ryzen R1600 CPU Cores / Threads 2 Cores / 4 Threads CPU Frequency 2.6 GHz Base / 3.1 GHz Turbo Installed Memory 4 GB DDR4 non-ECC SODIMM (1 × 4 GB) Memory Slots Maximum Memory 32 GB (2 × 16 GB) Drive Bays 2 × 3.5-inch SATA HDD / 2.5-inch SATA SSD Maximum Drive Bays 7 with DX525 Expansion Unit M.2 SSD Slots 2 × M.2 2280 NVMe LAN Ports 1 × 2.5GbE RJ-45, 1 × 1GbE RJ-45 USB Ports 1 × USB 3.2 Gen 1 Expansion Port 1 × Expansion Port Supported RAID Types SHR, Basic, JBOD, RAID 0, RAID 1; RAID 5, 6, 10 with Expansion Unit Operating System Synology DiskStation Manager (DSM) Dimensions (H × W × D) 166 × 106 × 223 mm Weight 1.51 kg Compatibility & Important Information Drive Compatibility: Supports compatible 3.5-inch SATA HDDs and 2.5-inch SATA SSDs. Storage drives are purchased separately. Memory Configuration: DS725neo+ includes 4 GB DDR4 non-ECC memory, unlike the DS725+ model with ECC memory. Use Synology-supported memory configurations for expansion. Expansion: One compatible DX525 expansion unit increases the maximum drive bay count to seven. The expansion unit is sold separately. Network Connections: Includes one 2.5GbE and one 1GbE port. It does not provide two built-in 2.5GbE ports. NVMe Storage: Two M.2 2280 slots support compatible NVMe SSD caching. NVMe drives are sold separately. RAID Requirements: RAID 5, RAID 6 and RAID 10 require an expansion unit and sufficient installed drives. Synology Drive Compatibility: Synology lists the Plus Series HAT3320-20T 20 TB HDD among the supported drives for this model. Package Contents Synology DiskStation DS725neo+ Main Unit Accessory Pack AC Power Adapter AC Power Cord 2 × RJ-45 LAN Cables Please to review Q: What is the difference between Synology DS725neo+ and DS725+? A: The DS725neo+ includes 4 GB DDR4 non-ECC memory, while the DS725+ includes 4 GB DDR4 ECC memory. Both models feature an AMD Ryzen R1600 processor and two drive bays. Q: Are hard drives included with the DS725neo+? A: No. Hard drives and SSDs are sold separately. The NAS supports compatible 3.5-inch SATA HDDs and 2.5-inch SATA SSDs. Q: Can I expand the DS725neo+ beyond two drive bays? A: Yes. The optional Synology DX525 expansion unit increases the total number of drive bays from 2 to 7. The expansion unit is sold separately. Q: Does the DS725neo+ support 2.5GbE networking? A: Yes. It includes one 2.5GbE RJ-45 LAN port and one 1GbE RJ-45 LAN port for wired network connectivity. Q: How much RAM does the DS725neo+ support? A: It comes with 4 GB DDR4 non-ECC SODIMM memory and supports expansion up to 32 GB using compatible memory modules. Q: Can I install M.2 NVMe SSDs in the DS725neo+? A: Yes. The NAS features two M.2 2280 NVMe slots for compatible SSD caching configurations. NVMe SSDs are sold separately. Q: Is the Synology HAT3320-20T 20 TB hard drive compatible with the DS725neo+? A: Yes. Synology lists the HAT3320-20T 20 TB SATA NAS hard drive among the compatible drives for the DS725neo+. Q: What operating system does the DS725neo+ use? A: It uses Synology DiskStation Manager (DSM), which provides tools for centralized file storage, backups, private cloud access, synchronization and storage management.
