| HARDWARE FEATURES | |
|---|---|
| Interface | 4 10/100Mbps LAN ports 1 10/100Mbps WAN port |
| Button | WPS/Wi-Fi Button Reset Button Power On/Off Button |
| External Power Supply | 9V/0.6A(EU), 9V/0.85A(US) |
| Dimensions ( W x D x H ) | 9.1 x 5.7 x 1.4 in. (230 x 144 x 35mm) |
| Antenna | 2 × 2.4GHz Antennas 1 × 5GHz Antenna |
| WIRELESS FEATURES | |
|---|---|
| Wireless Standards | IEEE 802.11ac/n/a 5GHz IEEE 802.11b/g/n 2.4GHz |
| Frequency | 2.4GHz and 5GHz |
| Signal Rate | 5GHz: Up to 433Mbps 2.4GHz: Up to 300Mbps |
| Reception Sensitivity | 5GHz: 11a 54M: -76dBm; 11ac VHT20 MCS8: -71dBm; 11ac VHT40 MCS9: -66dBm; 11ac VHT80 MCS9: -62dBm 2.4GHz: 11g 54M: -76dBm11n; HT20 MCS7: -73dBm; 11n HT40 MCS7: -71dBm |
| Wireless Functions | Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics |
| Wireless Security | 64/128-bit WEP,WPA / WPA2,WPA-PSK/ WPA2-PSK encryption |
| Transmission Power | CE: <20dBm(2.4GHz) <23dBm(5GHz) |
| SOFTWARE FEATURES | |
|---|---|
| Quality of Service | WMM, Bandwidth Control |
| Management | Access Control Local Management Remote Management |
| Port Forwarding | Virtual Server, Port Triggering, UPnP, DMZ |
| Dynamic DNS | DynDns, Comexe, NO-IP |
| VPN Pass-Through | PPTP, L2TP, IPSec |
| Access Control | Parental Control, Local Management Control, Host List, Access Schedule, Rule Management |
| Firewall Security | DoS, SPI Firewall, IP Address Filter/Domain Filter, IP and MAC Address Binding |
| Protocols | Supports IPv4 and IPv6 |
| Guest Network | 2.4GHz guest network × 1 5GHz guest network × 1 |
| OTHERS | |
|---|---|
| Certification | RoHS |
| Package Contents | AC750 Wireless Dual Band Router Archer C20 Power Adapter RJ45 Ethernet Cable Quick Installation Guide |
| Box Dimensions (W X D X H) | 14 x 8.8 x 2.7 in. (357x223x68mm) |
| System Requirements | Microsoft Windows XP/Vista/7/8/8.1/10, MAC OS, UNIX or Linux Internet Explorer, Firefox, Chrome, Safari or other Java-enabled browsers Cable or DSL or Fiber Modem/Terminal Subscription with an Internet Service Provider (for Internet access) |
| Environment | Operating Temperature: 0℃~40 ℃ (32 ℉~104℉) Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
| 5GHz | Up to 433Mbps |
|---|---|
| 2.4GHz | Up to 300Mbps |
| 11a 54M | -76dBm; 11ac VHT20 MCS8: -71dBm; |
| 11ac VHT40 MCS9 | -66dBm; 11ac VHT80 MCS9: |
| 11g 54M | -76dBm11n; HT20 MCS7: -73dBm; |
| 11n HT40 MCS7 | -71dBm |
| Operating Temperature | 0℃~40 ℃ (32 ℉~104℉) |
| Storage Temperature | -40℃~70 ℃ (-40 ℉~158℉) |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 5%~90% non-condensing |
