Specifications Interface - 9× 10/100/1000 Mbps RJ45 Ports (Ports 1–8 supports PoE+ output) - 1× Gigabit SFP Port Network Media - 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m); EIA/TIA-568 100Ω STP (maximum 100m) - 100BASE-TX: UTP category 5, 5e cable (maximum 100m); EIA/TIA-568 100Ω STP (maximum 100m) - 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m); EIA/TIA-568 100Ω STP (maximum 100m) Fan Quantity Fanless Installation - Desktop - Wall Mounting Physical Security Lock Yes Power Supply External Power Adapter (Output: 53.5VDC / 1.31A) PoE+ Ports(RJ45) - Standard: 802.3at/802.3af compliant - PoE Ports: Ports 1–8, up to 30 W PoE output per port - PoE Power Budget: 61W Dimensions ( W x D x H ) 8.2×4.9×1.0 in (209×126×26 mm) Max Power Consumption - 7.3 W (220/50Hz. no PD connected) - 76.96 W (220/50Hz. with 61 W PD connected) Max Heat Dissipation - 24.82 BTU/h (no PD connected) - 261.66 BTU/h (with 61 W PD connected) PERFORMANCE Switching Capacity 20 Gbps Packet Forwarding Rate 14.88 Mpps MAC Address Table Jumbo Frame 16 KB SOFTWARE FEATURES Advanced Features - Extend Mode Button (Ports 1–4, Up to 250 m PoE power supply and data transmission) - Isolation Mode Button (Ports 1–8) - PoE Auto Recovery Button (Ports 1–8) - Compatible With IEEE 802.3af/at Compliant PDs - IEEE802.3x Flow Control - 802.1p/DSCP QoS - IGMP Snooping - Green Technology Transmission Method Store-And-Forward OTHERS Certification CE, FCC, RoHS Package Contents - LS1210GP - Power Adapter - Installation Guide Environment - Operating Temperature: 0°C~40°C (32°F~104°F) - Storage Temperature: -40°C~70°C (-40°F~158°F) - Operating Humidity: 10% ~ 90% non-condensing - Storage Humidity: 5%~90% non-condensing Please to review
